FreeScan UE PRO

Contact Details

High-Precision Handheld 3D Laser Scanner for Metrology Applications

  • Achieve ultra-accurate 3D scans with 0.02 mm precision using reference markers.
  • Experience lightning-fast data capture at 1,850,000 points per second.
  • Equipped with three versatile scanning modes and integrated photogrammetry for maximum flexibility and detail.
  • Proud recipient of the Red Dot Design Award 2024.
SKU: FreeScan UE PRO Category:

Description

For High Precision Metrology-Grade Inspection

The FreeScan UE Pro combines the ultra-precise, metrology-grade accuracy and lightweight design of the FreeScan UE with upgraded capabilities for high-resolution detail scanning and enhanced global precision control, making it ideal for scanning large-scale workpieces with exceptional accuracy.

Metrology-Grade High Accuracy

With an impressive accuracy of 0.02 mm, it ensures reliable and highly precise scanning results every time.

Global Precision Control

Features built-in Video Photogrammetry (VPG) technology, eliminating the need for coded markers by rapidly securing the spatial positioning of the marker frame.

Multiple Scanning Modes

Utilizes 13 cross laser lines for rapid scanning of large objects, 7 parallel laser lines for capturing fine details, and a single laser line for deep hole and pocket area scanning.

Easy Operation

Inheriting the ergonomic and lightweight design of the UE series, it features intuitive scanning software that simplifies operation and minimizes the learning curve.

High-accuracy Scanning for Small to Large-Scale Objects

Featuring built-in photogrammetry, the FreeScan UE Pro delivers outstanding accuracy and detailed data capture across a wide range of object sizes, from small components to large-scale parts. It excels in various industrial applications and maintains high performance even in outdoor scanning conditions.

Unrelenting Accuracy and Precision

Ideal for quality control, inspection, and reverse engineering, it offers 0.02 mm* accuracy and delivers consistently reliable, high-precision results.

*Accuracy in accordance with VDI/VDE 2634 standards. Sphere-spacing errors are measured using traceable length artifacts and markers, evaluated at various positions and angles within the working volume. All assessments are conducted in an ISO/IEC 17025:2017 certified accuracy lab under controlled conditions: temperature at 20 ± 0.5℃ and humidity maintained between 40%–60% RH.

Video Photogrammetry (VPG)

FreeScan UE Pro integrates SHINING 3D’s patented Video Photogrammetry (VPG) technology, eliminating the need for coded markers.
Ensures stable volumetric accuracy and streamlines setup for efficient scanning of large objects.

Multiple Scanning Modes

  • 26 laser lines: Delivers a 600 × 550 mm scanning area for fast and efficient 3D data capture

  • 7 laser lines: Powered by 3.2MP industrial-grade cameras for high-resolution detail scanning

  • 1 single laser line: Optimized camera angle for accurate scanning of deep holes and pocket features

Fine and Rich Details

Featuring 3.2 Megapixel high-resolution cameras and 7 parallel laser lines, the FreeScan UE Pro enables precise scanning of intricate objects, ensuring accurate reproduction of fine details.

Special Pricing for Reverse Engineering Bundle

Elevate your engineering and design workflow with the professional reverse engineering bundle, combining the FreeScan UE Pro 3D Scanner and EXModel. This powerful duo delivers accurate and efficient solutions for industries needing precise conversion of physical objects into detailed digital CAD models.

Our Support Coverage

At SITML, we offer more than just devices — we deliver tailored solutions, nationwide support, and a dedication to your success. With user-friendly tools and precision-calibrated accuracy, we’re here to elevate your workflow.

What You Can Achieve with Our Scanners
Discover how incorporating our scanners into your workflow can boost productivity and deliver exceptional results with greater speed and precision.

The FreeScan UE Pro delivers high-speed scanning with smooth operation and exceptional accuracy, significantly reducing process iterations. It’s an ideal solution for scanning vehicle bodies to perform surface deviation analysis and to ensure the precise alignment of sheet metal hole positions.

With high scanning speed, smooth operation, and exceptional accuracy, the FreeScan UE Pro significantly boosts scanning efficiency without sacrificing precision. Its integrated photogrammetry function enhances volumetric accuracy, making it perfectly suited for large-scale components like aircraft fuselages, plane engines, and other oversized parts.

The FreeScan UE Pro combines a metrology-grade camera, built-in photogrammetry, and lightweight portability to deliver precise scanning performance in both indoor and outdoor environments. This versatility is essential for capturing large, high-accuracy datasets required for applications such as deformation analysis and damage detection in water turbines and petroleum drill bits.

The FreeScan UE Pro features three laser line modes, outstanding portability, and metrology-grade accuracy, delivering efficient and precise scanning in both indoor and outdoor settings. It is highly effective for capturing data on hull accessories and rail transit tracks, streamlining inspection and reverse engineering processes.

Enhance your Scan Experience with the FreeScan UE Pro Software



Step-by-step Guidance

The FreeScan UE Pro software provides step-by-step guidance throughout the 3D scanning workflow, from calibration to scanning and data editing.

Laser Real-time Mesh Scanning

Real-time mesh data capture during scanning minimizes unnecessary post-processing steps and significantly boosts user efficiency.

Data Quality Indicator

A data quality color indicator is now available in laser mode, visually displaying the quality of scanning data through color-coded feedback.

Partial HD Mode

Supports high-resolution settings for partial scanning of large-volume objects, capturing rich and finely detailed data in targeted areas.

Compatible Software

Technical Data

High-speed Scanning

26 laser lines

Deep Pockets

1 single line

Scan Accuracy

0.02 mm

Volumetric Accuracy

0.02 + 0.015 mm/m (with photogrammetry)

Point Distance

0.01~ 10 mm

Certifications

CE, FCC, ROHS, WEEE, KC, FDA, UKCA, IP50, TISAX

Detailed Scan

7 laser lines

Large Parts

Photogrammetry mode, no coded markers required

Scan Speed

1,850,000 points/s

Max. FOV

600 × 550 mm

Weight

840g

Accuracy Certification

VDl/VDE 2634 Part 3 (ISO 17025 certificated lab)

Download Brochure
